Specification
Image Sensor
2MP CMOS Image Sensor
Signal System
PAL/NTSC
Effective Pixels
1920(H)*1080(V)
Min. illumination
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time
1/25(1/30)s to 1/50,000s
Lens
2.8mm, 3.6mm optional
Angle of View
92°(2.8 mm),70.9°(3.6 mm)
Lens Mount
M12
Day & Night
ICR
Angle Adjustment
Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360°
Synchronization
Internal synchronization
Video Frame Rate
1080p@25fps/1080p@30fps
HD Video Output
1 Analog HD output
S/N Ratio
＞62dB
Operating Conditions
-20°C-45°C(-4°F-113°F), Humidity 90% or less (non-condensing)
Power Supply
-12 VDC±15%
Power Consumption
Max. 4W
IR Range
Up to 20m
Dimension
Φ90 × 69.8 mm(Φ3.54” × 2.75”)
Weight
250g
